Lead Lined Wooden Door

Construction Details

• Frame Manufactured out of Hardwood Mirandi / Teakwood of nominal section 120mm x 70mm with 2mm sandwiched Lead Sheet
• 2mm (+–1%) Lead sheet with 99% purity
• Total Door Shutter thickness with Commercial Ply on both side & Board will have 43mm thickness (with additional laminate shutter thickness will be 46mm)
• Vision Panel if required shall be of lead glass only

Recommended Hardware

• Stainless Steel Ball Bearing Hinges - Size 102 x 89 x 3mm
• Door Closer - Heavy duty only for 80 kg weight capacity
• Door coordinator recommended
• Exposed Tower bolt
• Mortise Sash Lock with half cylinder, estucheon, lever handle - Complete Set for Push / Pull operation
• Mortise Dead Lock Set with Half Cylinder and estucheon - Complete Set with D Shape Pull Handle pull side & push plate SS 304 Grade on push side
• Weight of door shutter will be 40 kg/sqm

Optional Hardware

• Automatic DROP DOWN DOOR BOTTOM Non Mortised / Surface Mounted
• Optional Lead Lined door sill to cover the gap between finished floor and door shutter
• Lead Lined architrave to be used

Optional Hardware

• Automatic DROP DOWN DOOR BOTTOM Non Mortised / Surface Mounted
• Optional Lead Lined door sill to cover the gap between finished floor and door shutter
• Lead Lined architrave to be used

Recommended Finishes

• Primer and Paint finish
• Teakwood: Polish finish
• Door Shutter:
• One side laminate /veneer and one side painting with VIPER
• Both Sides Laminate / Veneer
